Pureflo

FILTERLESS VACUUM RECEIVERS
  • Optimal material separation - typically more than 99.99%
  • Abrasion resistant right-angle material inlet
  • Low operating costs due to lack of screen filter maintenance

    Please insert your data, we will send you an e-mail with the link to download the file.

    Kontaktieren Sie uns

    Pureflo eliminates the need for ordinary maintenance of the vacuum receiver (filter cleaning) and improves the conveying capacity of the overall system.

    The plastic granule moves through the conveying pipes carried by an airflow generated at negative pressure by a vacuum unit.
    The velocity the plastic granule reaches during conveying varies between 15 metres/second at the pick-up point and 25 metres/second at the end of the line.

    In a conventional solution the plastic granule enters the receiver at the end velocity, ie 25 metres/second, and stops by hitting on the inner walls of the receiver body.

    The innovative and unique design of Pureflo allows the plastic granule not only to keep its end velocity all the way into the receiver body but, through a Right Angle bend, to dissipate the entire kinetic force it picked up during conveyance.
    The granules fall into the receiver body, where they have a residual speed of 1 metre/second. It directs the flow to the base of the receiver where the air gradually lose pressure and velocity.

    • More efficient conveying - system pressure drop never changes
    • No more plugged line and capacity problems due to plugged screen filters
    • No compressed air blowback system required – provides cleaner plant environment
